High flow ，Customisable Industrial 304 Stainless Steel 10 Inch Cartridge Filter Housing

High flow ,Customisable Industrial 304 Stainless Steel 10 Inch Cartridge Filter Housing

Gas filter is suitable for natural gas, the artificial coal gas and other corrosive gases, such as nitrogen, carbon dioxide, propane, butane gas liquid and liquid-solid separation, gas pipeline and gas transmission pipeline is used QiZhan, pressure QiZhan, distribution station, at the end of the pigging station, station and various application fields necessary separation purification equipment components, dirt, and can effectively filter the pipe walls crumbling to pieces, to ensure the safe operation of gas transmission and gas equipment, quality of gas pipeline and user requirements.

Main functions: filter out metal iron cutting, sand, wood cutting and other solid particles impurities and water in the filter medium.
3. Maximum working pressure: 35MPa.
4. Maximum flow: 800L/min.
5. Operating temperature: -50℃~200℃.
6. Filtration accuracy: 2, 5, 10, 20, 30, 60, 80, 100, 200.
7. Filtering materials: stainless steel mesh, copper wire mesh, glass fiber, filter paper, polyester fiber, etc.Material properties:
Ultipor?- Glass fiber resin bond filter element, hard glass fiber impregnated in the resin colloid.Form a filter material with a stable opening rate.The stability of the opening can effectively prevent the rediffusion of the fixed pollutant.Ultipor?The material improves the filter element's fouling performance, reduces the pressure drop and improves the filter element's service life.Reduces the processing cost of purifying each gallon of liquid.
Epocel?- Resin impregnated cellulose filter element, filter material consisting of other cellulose and impregnated resin.The resin can fix the cellulose fiber and control the size of the hole so as to control the filtration efficiency.Epocel?- Resin impregnated cellulose material is synthesized from multiple different materials and a variety of cellulose (including fresh water and many liquids, acids, solvents, brines, hydrocarbons, alcohols, etc.).This material can meet the absolute precision of 10um to 50um filtering requirements.

Criteria for determining the performance of filter elements:
(1) Absolute filtration accuracy: the measurement of absolute precision can be defined operationally
= 5000/99.98%, the size of any given removal efficiency.
Note: This is the highest value of the rating method.
(2) value () : is the ratio of the particle size to a given number
In the water or larger than those of the same size or larger in the wastewater.
Is related to removal rate: removal efficiency % = -1 × 100
(3) The nominal length of the base 33/4 "OD. 40" listed.
(4) The rating was determined as McC1401u2-20 siliceous pollutants from 0.5 microns to 40 microns.General for other MCC1401 rate determination (5) specially designed for high temperature applications.
(6) Sodium chloride aerosol test.The replacement number is at the particle % specified size or greater.
(7) Pressure drop for each GPM PSID displayed filter element.This value is multiplied by the total flow of the system to determine the water pressure drop.The next step is to ratio the liquid out of the water times the viscosity of the fluid at this value operating temperature.This is the entire pressure drop filter.It must be added to the pressure drop filter precision filter element made of European high-quality filter materials and stainless steel framework, with high filtration efficiency, corrosion resistance, high strength, low airflow resistance, long service life and other characteristics.The outer layer of the precision filter element is made of hydrophobic foam sleeve which is resistant to oil and acid chemical corrosion, preventing coalescing liquid from re-entering the air stream and ensuring high efficiency of oil and water removal.Jiaze filter industry mainly serves steel, petrochemical, paper, packaging, power, shipping, mining, food, feed and so on.And with most of the large enterprises in these industries to establish direct or indirect cooperation model.
